WEINZIERL 5314 KNX Dimmaktor 4 channels CV
€121,11 Excl. tax
€159,80 Excl. tax
€146,54 Incl. tax €193,36 Incl. tax. Out of stock, but available
€146,54 Incl. tax €193,36 Incl. tax. Out of stock, but available
Compact RGB, RGBW, and Tunable White dimming actuator with 4 PWM outputs. Ideal for LED panels, strips, or 4 dim channels. Offers scenes, staircase light, and logic functions. Read more
Specifications
Brand:
Weinzierl
Article number:
5314
EAN:
4260262773142
Availability:
Out of stock, but available
Delivery time:
Will be shipped within approximately 8 working days.
Information
KNX IO 534 CV (4D) - RGB, RGBW, and Tunable White Dimming Actuator (Article number: 5314)
The KNX IO 534 CV (4D) is a versatile and compact dimming actuator with four independent PWM outputs. It is ideal for controlling RGB, RGBW, and Tunable White LED panels or strips, offering advanced lighting and automation options.
Main Features
- Supports RGB, RGBW, and Tunable White configurations.
- Usable as four independent dim channels or in RGB/RGBW mode.
- Maximum load of 6 A, freely distributable across outputs.
- Additional functions such as scenes, staircase light, sequences, and logic control.
- Local control via two buttons and three multicolored LED indicators.
- 16 logical and time-controlled functions for advanced automation.
Technical Specifications
- Outputs: PWM signal, frequency adjustable to 480 or 600 Hz.
- Supply voltage: 12 – 24 V⎓, depending on the connected LED load.
- Maximum output current: 6 A (distributed across all channels).
- Maximum output power: Up to 144 W at 24 V⎓.
- KNX programming: Compatible with ETS version 4.2 or higher.
- Protection class: IP20, electronically protected against short circuit and overheating.
- Mounting: DIN rail (1 TE width), suitable for installation in distribution boxes.
- Operating temperature: -5 °C to +45 °C.
- Storage temperature: -25 °C to +70 °C.
- Connections:
- KNX Bus: red/black terminal.
- Plug-in 3-pole screw terminals for channels and power supply.
Certifications and Compatibility
- Meets CE directives: EMC 2014/30/EU and RoHS 2011/65/EU.
- Protection against overload and short circuit.
- Compatible with various KNX installations.
Note: This device is designed for use in dry indoor environments and provides reliable performance for a wide range of lighting applications.
