N 535D51 Switching actuator 8 x AC 230 V, 16/20 AX, C-Load
€285,48 Excl. tax
€549,00 Excl. tax
€345,43 Incl. tax €664,29 Incl. tax. Out of stock, but available
€345,43 Incl. tax €664,29 Incl. tax. Out of stock, but available
This switching actuator provides eight potential-free outputs for switching electrical loads. Suitable for switching capacitive, inductive, and resistive loads. Diagnostic functions and configuration via KNX. Read more
Specifications
Brand:
Siemens
Article number:
5WG1535-1DB51
EAN:
7612914108647
Availability:
Out of stock, but available
Delivery time:
Will be shipped within approximately 8 working days.
Information
Switching Actuator 8-fold AC 230V, 16/20 AX, C-Load
The Siemens N 535D51 switching actuator provides eight potential-free outputs for switching electrical loads. Suitable for resistive, inductive, and capacitive loads, including lighting with high inrush currents such as fluorescent lamps. The actuator can be configured and controlled via the KNX system.
Key Features
- 8 potential-free relay outputs (bistable)
- Suitable for resistive (incandescent lamps), inductive (motors, halogen lamps), and capacitive (fluorescent lamps) loads
- Supports high inrush currents up to 600 A (150 µs) and 480 A (250 µs)
- Diagnostic functions per channel with current detection and limit monitoring
- Adjustable on and off delay
- Switching modes: normal operation, timer operation, flashing
- Adjustable relay mode: opener or closer
- Supports logical operations (AND, OR, XOR, etc.)
- 8-bit scene control with up to 8 scene assignments per output
- Manual operation possible for each output
- Runtime and switch cycle monitoring with limit control
Technical Specifications
- Rated voltage: AC 230 V, 50/60 Hz
- Rated current: 16/20 A per channel
- Number of outputs: 8 potential-free bistable relays
- Max inrush current: 600 A (150 µs), 480 A (250 µs)
- Switching capacity (resistive load): Max 3680 W per channel
- Capacitive load: Max 200 µF per channel
- Operating temperature: -5°C to +45°C
- Protection class: IP 20
- Dimensions: 8 modules wide (144 mm, 4 TE)
- Lifetime: Mechanically 1,000,000 switching cycles
- KNX current consumption: 20 mA
- KNX power loss: 0.2 W
Note: This device supports extensive diagnostic functions and configuration options via KNX. It can be used for switching various electrical loads and provides high reliability and flexibility. Thanks to the integrated current detection per channel, potential issues can be detected and resolved early.
Certifications
- KNX certificate
- EAC certificate
- CE mark
