KNX RF+ Wireless Line Coupler Flush-Mounted
€216,75 Excl. tax
€289,00 Excl. tax
€262,27 Incl. tax €349,69 Incl. tax. Out of stock, but available
€262,27 Incl. tax €349,69 Incl. tax. Out of stock, but available
The KNX RF+ line coupler connects KNX RF+ devices to the KNX bus, reducing load. From ETS6, it can function as a segment coupler. Compact and flush-mounted. Read more
Specifications
Brand:
MDT
Article number:
RF-LK001.03
EAN:
4251916100179
Availability:
Out of stock, but available
Delivery time:
Will be shipped within approximately 8 working days.
Information
KNX RF+ Line Coupler (Flush Mount)
The KNX RF+ line coupler connects KNX RF+ devices to the wired KNX bus system. With integrated filter functions, it significantly reduces the load on the RF+ network. This device supports both ETS 5 and ETS 6 and can function as a segment coupler starting from ETS 6.
Key Features:
- Operates at 868 MHz for EU regions
- Supports the latest KNX RF+ protocol in system mode
- Commissioning with ETS 5 and ETS 6
- Segment coupler functionality from ETS 6
- Filter functions to reduce bus load
- Flush mount in installation box
- Dimensions: 41 mm x 41 mm x 22 mm
- Integrated bus coupling unit
- Protection class: IP20
- Powered by the KNX bus with low power consumption (< 0.3 W)
Technical Data:
- Frequency: 868.3 MHz
- Range in open field: 150 meters
- Output power: 10 dBm
- Sensitivity: > -105 dBm
- Compatibility: KNX RF S-Mode
- KNX interface: TP-256, Long Frame Support
- Operating temperature: 0°C to 45°C
