MDT STV-0024.01 Power Supply | 750 mA
€67,20 Excl. tax
€80,00 Excl. tax
€81,31 Incl. tax €96,80 Incl. tax. In stock (1)
€81,31 Incl. tax €96,80 Incl. tax. In stock (1)
Universal 24 V DC power supply suitable for various applications such as MDT VisoControl, binary inputs, and window contacts. Not for KNX bus use. Read more
Specifications
Brand:
MDT
Article number:
STV-0024.01
EAN:
4251916100049
Availability:
In stock (1)
Delivery time:
Will be shipped within 1 to 2 working days.
Information
Assembly and operational instructions
MDT STV-0024.01 Power Supply 24 V DC | 750 mA
The MDT STV-0024.01 is a universal 24 V DC power supply suitable for various applications such as MDT VisoControl touch panel, binary inputs, window contacts, and more. Note: Not suitable for use as a KNX bus power supply.
Technical Data
- Input Voltage: 230 V AC / 50 Hz
- Output Voltage: 24 V DC
- Maximum Output Current: 750 mA
- Enclosure: 4 SU wide, IP20
- Permitted Circuit Breaker: 16 A
- Terminals: Screw terminals for 0.5 - 2.5 mm² solid core
- Operating Temperature: 0 ... 45°C
Important: This device must be installed by qualified electrical personnel following the relevant standards and regulations. Approved for use in the EU and UK, marked with CE and UKCA. Not suitable for use in the USA and Canada.
