The 6-gang KNX push-button is ideal for switching, dimming, blinds, and scene control. With an orientation LED and configurable buttons, it offers flexible smart building features. Read more
Specifications
Brand:
MDT
Article number:
BE-TA55P6.02
EAN:
4251916112424
Availability:
Out of stock, but available
Delivery time:
Will be shipped within approximately 8 working days.
Information
Push-button Plus 55 | series .02
MDT Push-button Plus 55 6-gang
The MDT Push-button Plus 55 6-gang offers flexible control and is compatible with numerous switch series from leading manufacturers. Available in matte white, glossy white, and matte black, this push-button supports a wide range of functions including switching, dimming, and blind control. The central labelling field allows easy customization of functions. Each button surface is equipped with an individually controllable LED (red/green), capable of indicating different statuses.
Main Features:
- Available colors: matte white, glossy white, matte black
- 6-gang operation with programmable buttons for switching, dimming, blinds, and scenes
- Central labelling field with protective foil for individual marking
- Integrated logic functions with 4 logic blocks
- 2/4/6/8 control and status LEDs (red/green) with orientation light
- Maximum cable cross-section KNX bus connection: Ø 0.8 mm, solid core
- Power supply: KNX bus, consumption < 0.3 W
- Protection class: IP20
- Dimensions: 55 mm x 55 mm x 13 mm
Technical Specifications:
- KNX interface: TP-256
- Available in the KNX database from ETS 5
- Ambient temperature: 0 ... +45 °C
- Integrated bus coupling unit
- Warranty: 3 years
The MDT Push-button Plus 55 is ISO 9001 certified and made in Germany. Compatible with 55 mm switch ranges such as GIRA, BERKER, JUNG, and MERTEN.
Other available article numbers in this series:
- BE-TA55P2.02 Push-button Plus 55 2-gang, matte white
- BE-TA55P2.G2 Push-button Plus 55 2-gang, glossy white
- BE-TA55P206.02 Push-button Plus 55 2-gang, matte black
- BE-TA55P4.02 Push-button Plus 55 4-gang, matte white
- BE-TA55P4.G2 Push-button Plus 55 4-gang, glossy white
- BE-TA55P406.02 Push-button Plus 55 4-gang, matte black
- BE-TA55P6.02 Push-button Plus 55 6-gang, matte white
- BE-TA55P6.G2 Push-button Plus 55 6-gang, glossy white
- BE-TA55P606.02 Push-button Plus 55 6-gang, matte black
- BE-TA55P8.02 Push-button Plus 55 8-gang, matte white
- BE-TA55P8.G2 Push-button Plus 55 8-gang, glossy white
- BE-TA55P806.02 Push-button Plus 55 8-gang, matte black
Series name: Push-button Plus 55 | series .02
