8-fold Jal.actor 8A, with travel time measurement 230VAC up to 300W

0 Review(s)

€340,34 Excl. tax €523,60 Excl. tax
€411,81 Incl. tax €633,56 Incl. tax. In stock (2)

Unit price: €340,34 / Piece

The JAL Shutter Actuator 8-fold precisely controls blinds and shutters with features like automatic sun shading, manual operation, and time measurement. Ideal for both residential and commercial applications. Read more

Specifications

Brand:

MDT

Article number:

JAL-0810M.02

Availability:

In stock (2)

Delivery time:

Will be shipped within 1 to 2 working days.

Information

Datasheet

JAL-0810M.02 Shutter Actuator 8-fold - Technical Specifications

The JAL Shutter Actuator 8-fold is an advanced control device for managing blinds and shutters. The device offers extensive functionality, including:

Production: Engelskirchen, certified according to ISO 9001
Application: Comprehensive application
Travel Time Measurement: Yes, only for JAL-0x10M.02
Manual Operation: Lockable with LED indicator per channel
Operating Mode: Blind/Shutter
Ventilation Function: Practical function for open/tilted windows
Automatic Sun Shading: With slat adjustment and sun position calculation (excluding JAL-01UP.02)
Time Settings: Freely adjustable travel, pause, and step times
Precise Control: Separate travel times for up/down adjustable
Tip Operation: For precise positioning
Advanced Functions: Extended 1Bit automatic positions and scene functions
Positioning: 1Byte absolute positioning for height and slats
Alarm Functions: Alarm, central, and block functions
Adjustable Behavior: Behavior after alarm and blocking individually adjustable
Priority Settings: Priority/forced operation with automatic fallback time
Bus Voltage: Adjustable behavior in case of bus voltage failure/return (excluding JAL-01UP.02 and JAL-0210.02)
Connections: Two L-connections internally bridged (modular device), common L-connection (flush-mounted device)
Quick Download: Supports long frame download for ETS5
Warranty: 3 years product warranty
Dimensions: 8SU (modular device)
Power Supply: 230VAC, 50Hz
Operating Temperature: 0 to +45°C

This product is designed and manufactured in Germany according to the highest quality standards. It provides reliable and precise control of blinds and shutters, making it ideal for both residential and commercial applications.
