DINUY IT KNT 008 8-channel switch/blind actuator, 12 inputs
€268,32 Incl. tax €477,01 Incl. tax. In stock (2)
Specifications
Information
8-Channel Switching/Blinds Actuator with 12 Inputs
The IT KNT 008 is a versatile actuator with 8 switching channels or 4 channels for blinds control, equipped with 12 inputs (8 binary and 4 binary/analog inputs). It is programmable via ETS5 and supports high loads up to 16A, making it suitable for capacitive loads such as motors or lighting.
Main Features
- 8 Switching Channels or 4 Blinds Channels
- 12 Inputs: 8 binary and 4 binary/analog inputs
- Supports high loads up to 16A per channel
- Zero-crossing control for optimized switching actions
- Configurable logic functions, scenes, and timing functions
- Manual control and status LED indicators on the front
- Possibility to connect different phases for each channel
- Programmable via ETS5 or later versions
Technical Specifications
- Nominal Voltage: 230V, 50Hz
- Maximum Switching Capacity: 16A per channel
- LED Loads: 400W
- Incandescent and Halogen Lamps: 3000W
- Motor Load: 700VA
- Number of Inputs: 12 (8 binary + 4 binary/analog)
- Protection Rating: IP20
- Operating Temperature: -5ºC to +45ºC
- Dimensions: 4 DIN modules wide
The IT KNT 008 offers flexibility and high performance for advanced home or building automation systems. With simple DIN-rail mounting and full compatibility with the KNX system, this actuator is a powerful addition to any automation solution.
