Siemens IP Router Secure N 146/03
€314,60 Excl. tax
€605,00 Excl. tax
€380,67 Incl. tax €732,05 Incl. tax. Out of stock, but available
€380,67 Incl. tax €732,05 Incl. tax. Out of stock, but available
Connects KNX lines via IP networks for secure data transmission using KNXnet/IP Secure. Supports ETS configuration and PoE. Flexible as line or area coupler. Read more
Specifications
Brand:
Siemens
Article number:
5WG1146-1AB03
EAN:
4001869378558
Availability:
Out of stock, but available
Delivery time:
Will be shipped within approximately 8 working days.
Information
IP Router Secure N 146/03
The IP router connects KNX lines with data networks via the Internet Protocol (IP) using the KNXnet/IP standard. It also allows bus access from a PC or other data processing devices. The router provides secure data transmission via KNXnet/IP Secure and supports encrypted communication with authenticated devices.
Main Features
- Connects KNX lines via IP networks for secure data transfer.
- Supports ETS configuration and Power over Ethernet (PoE).
- Flexible as line, area, or system coupler.
- Encrypted communication with authenticated devices.
- Compatible with visualization and facility management systems.
- 5 LED indicators for status of KNX and IP communication.
Technical Specifications
- Network communication: Ethernet (10BaseT, 100BaseT), supported protocols: ARP, ICMP, IGMP, TCP/IP, UDP/IP, DHCP, AutoIP.
- Power supply: Power over Ethernet (48 V DC, IEEE 802.3af) or external power supply (AC/DC 24 V).
- KNX network: KNX bus voltage 24 V DC (21-30 V), consumption 4 mA.
- Housing: Plastic, color RAL 7035 (light gray).
- Dimensions: DIN-rail TH35, protection class IP 20.
- Operating temperature: -5 °C to +45 °C.
- Storage temperature: -25 °C to +70 °C.
Note: This device requires ETS 5.7.3 or higher for configuration.
