Dinuy FA KNT 001 KNX Power supply 640mA
640mA power supply for EIB/KNX systems with integrated choke and 30VDC auxiliary output for an additional bus line. Read more
Specifications
Brand:
Dinuy
Article number:
FA KNT 001
EAN:
8422447015003
Availability:
In stock (5)
Delivery time:
Will be shipped within 1 to 2 working days.
Information
640mA Power Supply for EIB/KNX Systems with Auxiliary Output
The 640mA power supply is designed to supply and monitor the system voltage for EIB/KNX installations. This unit not only provides a reliable power supply for the bus line, but also includes an integrated choke that decouples the bus line from the power supply, ensuring stable and interference-free operation of the system.
- Output current: 640mA
- System voltage: 30V DC
- Auxiliary output: 30V DC, available via an additional terminal
- Maximum power output: 640mA on the bus line
- Additional output for supplying a second bus line (with separate choke)
- Installation: Standard DIN-rail mount
- Temperature range: -5°C to +45°C
- Dimensions: 72 x 90 x 60 mm
- Certifications: CE, KNX
Important note: The device comes with an integrated choke that ensures the necessary decoupling between the bus line and the power supply. A separate choke must be used for an additional bus line.
