DINUY DM.K5X.001 motion sensor on battery KNX-RF

152,22 Excl. tax €270,61 Excl. tax
€184,19 Incl. tax 327,44 Incl. tax.
Out of stock, but available
Unit price: €152,22 / Piece
Wireless KNX-RF motion sensor with PIR technology and daylight sensor. Recessed ceiling mount, battery-powered with >10 years lifespan. 360º detection, Ø7m range at 2.5m height. Programmable via ETS5. Read more

Specifications

Brand:
Dinuy
Article number:
DM.K5X.001
EAN:
8422447016970
Availability:
Out of stock, but available
Delivery time:
Will be shipped within approximately 8 working days.

Information

Datasheet

Instructions

Product Description DM.K5X.001

The wireless KNX-RF motion detector with infrared technology is designed for recessed ceiling mounting and is powered by a battery with a lifespan of over 10 years. This sensor is equipped with a highly sensitive PIR sensor that, together with its lens design, detects even the slightest movements within the coverage area. The integrated light sensor allows its functionality to be restricted to daylight. The built-in potentiometer enables the adjustment of delay time from the last detection. All parameters can be programmed via ETS5 or later versions.

Key Features:

  • Built-in PIR motion sensor for accurate detection
  • Daylight sensor for energy savings
  • Adjustable delay time and luminosity via ETS5
  • Recessed ceiling mounting, wireless
  • Battery life: more than 10 years
  • Detection angle: 360º, range: Ø7m at 2.5m height
  • Operational temperature: -5ºC to +45ºC

Technical Specifications:

  • Power supply: 1 battery 3.6V LS14250
  • Battery life: >10 years
  • Radio frequency: 868.3MHz
  • Protection rating: IP20
  • Detection range: Ø7m at 2.5m height
  • Detection angle: 360º
  • Working temperature: -5ºC to +45ºC
  • Programmable via ETS5
