Dinuy CO KNT IPR -ROUTER KNX IP SECURE
€350,12 Excl. tax
€622,43 Excl. tax
€423,65 Incl. tax €753,14 Incl. tax. Out of stock, but available
€423,65 Incl. tax €753,14 Incl. tax. Out of stock, but available
The KNX IP Secure Router forwards telegrams between different lines via a LAN network and connects a PC to the KNX network for ETS programming. KNX security is activated. Read more
Specifications
Brand:
Dinuy
Article number:
CO KNT IPR
EAN:
8422447017915
Availability:
Out of stock, but available
Delivery time:
Will be shipped within approximately 8 working days.
Information
KNX IP Secure Router - Safe and Reliable
The KNX IP Secure Router forwards telegrams between different KNX lines via a LAN (IP) network, serving as a fast backbone. This device allows connecting a PC to the KNX network for ETS programming. The router supports KNX Secure for secure communication.
Key Features
- Forwards telegrams between KNX lines via LAN
- Supports KNX Secure for secure communication
- Suitable for ETS programming via PC connection
- IP address can be configured manually or obtained via DHCP
- Extended filter table for main group 0..31
- Stores up to 150 telegrams
- Power supplied via KNX bus
Technical Specifications
- Power via KNX bus: 29V
- Power consumption: 20mA
- Relative humidity: 5% - 93%
- Temperature range: -25°C to 70°C (storage), -5°C to 45°C (operation)
- Mounting: DIN rail, 1 TE (18 mm)
- Protection level: IP20 according to EN60529
- Directives: EMC 2014/30/UE, RoHS 2011/65/UE
