2 fold Dimming Actuator AKD ,230VAC, 250W

0 Review(s)

€234,00 Excl. tax €360,00 Excl. tax
€283,14 Incl. tax €435,60 Incl. tax. In stock (4)

Unit price: €234,00 / Piece

Dimmer für 230V LED-Lampen mit 2 Kanälen bis 250W pro Kanal. Unterstützt Phasenanschnitt und Phasenabschnitt, aktive Leistungsmessung und zeitabhängiges Dimmen. Überlast- und Kurzschlussschutz. Read more

Specifications

Brand:

MDT

Article number:

AKD-0201.02

EAN:

4251916130022

Availability:

In stock (4)

Delivery time:

Will be shipped within 1 to 2 working days.

Information

Datasheet

Dimmer Actuator AKD 2-Fold

The MDT Dimming Actuator AKD-0201.02 is an advanced dimming device optimized for dimmable 230V LED lamps. This device offers extensive configuration options, including the ability to dim lighting based on the time of day. Additionally, the lighting can be adjusted according to astronomical sunrise and sunset.

Key Features

2 channels, each with a maximum load of 250W, or parallel operation of 500W.
Supports both leading-edge and trailing-edge dimming, allowing a wide range of lamps to be used, including older LED lamps that only work with leading-edge dimming.
Active power measurement per channel, with the consumption values sent to the bus.
Built-in diagnostic functions that calculate channel load and send it as a 14-byte telegram in plain text.
Protection against overload, short circuit, and overheating, with an alarm message.
Time-dependent dimming functions, such as automatic dimming to avoid high brightness during evening hours.
Soft start, with both global and individual dimming speed adjustable per channel.
Day/night function for flexible lighting.
Manual operation possible via push buttons and status indicators for each channel.
Support for various phase connections (L1, L2, L3).
Compatible with KNX and EIB systems for seamless integration.
Designed and manufactured in Germany, with a 3-year warranty.

Technical Specifications

Feature	AKD-0201.02
Number of outputs	2
Output supply voltage	230VAC/50Hz
Max. fuse per channel	10A
Possible load per channel	2 x 250W or 1 x 500W
Minimum lamp load per channel	2W
Operating temperature range	0 to +45°C
Dimensions	3SU

Note: It is recommended to use the ETS software for project design and commissioning of the MDT Dimming Actuator. The software is available at www.mdt.de/Downloads.html.
